AWS : Redirect HTTP to HTTPS

It has been a headache to enforce HTTPS for applications running on EC2 (Elastic Compute Cloud) , if you are encountering the same challenge then you should read below.





Case 1 : application is powered by Elastic Beanstalk with Tomcat

Solution :
edit /etc/httpd/conf.d/elasticbeanstalk.conf

	<!-- /etc/httpd/conf.d/elasticbeanstalk.conf -->
	<virtualhost>
	...
	RewriteEngine On
	RewriteCond %{HTTP:X-Forwarded-Proto} !https
	RewriteRule !/status https://%{SERVER_NAME}%{REQUEST_URI} [L,R]
	</virtualhost>

view raw elasticbeanstalk.conf hosted with ❤ by GitHub

Case 2 : application is running in tomcat with or without apache httpd service on EC2 only

Solution:

edit server.xml

	<connector enablelookups="false" port="8080" redirectport="443">
	</connector>

view raw AWS : http redirects to https server.xml hosted with ❤ by GitHub

edit web.xml

	<security-constraint>
	<web-resource-collection>
	<web-resource-name>Protected Context</web-resource-name>
	<url-pattern>/*</url-pattern>
	</web-resource-collection>
	<user-data-constraint>
	<transport-guarantee>CONFIDENTIAL</transport-guarantee>
	</user-data-constraint>
	</security-constraint>

view raw AWS : http redirects to https web.xml hosted with ❤ by GitHub

Both above 2 solutions won't work , because SSL is configured at load balancer layer not application container level with aws.

You would end up infinite loop as request coming on unsecured channel (80 or 8080) is redirected to load balancer on 443 ,and load balancer would send request to unsecured port (80 or 8080), then this unsecured port would be redirected to load balancer 443 again , the loop never ends.

A working solution would be there are 2 containers (tomcat) listening on different unsecured ports , one (8089) is purely for redirect to secured channel another (8080) is where actual application is deployed.

I use spring boot for purpose of redirecting (from 8089 to 443) which you can download the source from there : https://github.com/junjun-dachi/spring-util/tree/master/spring-boot-enforce-https and a sample code below:

	package org.junjun.spring.util;
	import org.apache.catalina.Context;
	import org.apache.catalina.connector.Connector;
	import org.apache.tomcat.util.descriptor.web.SecurityCollection;
	import org.apache.tomcat.util.descriptor.web.SecurityConstraint;
	import org.springframework.boot.SpringApplication;
	import org.springframework.boot.autoconfigure.SpringBootApplication;
	import org.springframework.boot.context.embedded.EmbeddedServletContainerFactory;
	import org.springframework.boot.context.embedded.tomcat.TomcatEmbeddedServletContainerFactory;
	import org.springframework.context.annotation.Bean;
	@SpringBootApplication
	public class Application {
	public static void main(String[] args) {
	SpringApplication.run(Application.class, args);
	}
	@Bean
	public EmbeddedServletContainerFactory servletContainer() {
	TomcatEmbeddedServletContainerFactory tomcat = new TomcatEmbeddedServletContainerFactory() {
	@Override
	protected void postProcessContext(Context context) {
	SecurityConstraint securityConstraint = new SecurityConstraint();
	securityConstraint.setUserConstraint("CONFIDENTIAL");
	SecurityCollection collection = new SecurityCollection();
	collection.addPattern("/*");
	securityConstraint.addCollection(collection);
	context.addConstraint(securityConstraint);
	}
	};
	tomcat.addAdditionalTomcatConnectors(createHttpConnector());
	return tomcat;
	}
	private Connector createHttpConnector() {
	Connector connector = new Connector("org.apache.coyote.http11.Http11NioProtocol");
	connector.setScheme("http");
	connector.setSecure(false);
	connector.setPort(8089);
	connector.setRedirectPort(443);
	return connector;
	}
	}

view raw Application.java hosted with ❤ by GitHub

Type below on the command line to run the application :

nohup $JAVA_HOME/bin/java -jar spring-enforce-https.jar > /dev/null 2>&1 & echo $! > run.pid




Reference :

1 : http://msnider.github.io/blog/2013/12/06/force-https-slash-ssl-on-amazon-elastic-beanstalk/

2 : http://www.emind.co/how-to/how-to-force-https-behind-aws-elb

3 : https://edwardsamuel.wordpress.com/2015/07/17/enable-https-and-http-redirect-on-aws-elastic-beanstalk/

4 : http://tkurek.blogspot.sg/2013/07/tomcat-7-http-to-https-redirect.html
